TUF-2000B/TM-1 Ultrasonic Flow Meter, IP67 Digital Wall Mounted/Din-Rail Mounting Liquid Flowmeter Tester Flowmeter Module for DN32~DN6000mm Pipe (US Stock)

Basic Parameters: Protection Level: Main Unit IP67 /Transducer IP68Humidity: ≤85% Accuracy: ≤1%Velocity range: 0~±10m/s, Bi-directional measurementPipe size: DN32~DN6000mmTemperature: Temperature: Main Unit -20~60℃ /Transducer IP68 -30~90℃Type of liquid: Single liquid can transmit ultrasound, such as water, sea water, sewage, oil, alcohol, etc.Pipe material: Steel, stainless steel, copper, PVC, aluminmum, glass steel, etc. Liner is allowed.Signal output: 1 way 4-20mA output /1 way OCT pulse output /1 way Relay outputSignal input: 3 way 4-20mA input, achieve to heat measurement by connecting PT100 platinum resistor.Interface: RS485, support MODBUSData storage: SD card regularly store the pre-set results(optional)Power supply: DC8~36V or AC85~264VMultiple Installation Methods:Installation methods: Wall mounting and Two ways of Din-rail mountingPackage including:1 x TUF-2000B Host1 x Steel Belt 1 x TM-1 Ultrasonic Transducer2 x 5 meters Flow Signal Cable

• ★MAIN PARAMETERS 1 - Signal output：1 way 4-20mA output, 1 way OCT pulse output, 1 way Relay output; Signal input：3 way 4-20mA input, achieve to heat measurement by connecting PT100 platinum resistor; Package size: 16'' x 10'' x 7''; Package weight: 5 lbs.
• ★MAIN PARAMETERS 2 - Power supply：DC 8V-36V or AC 85V-264V; Pipe size：DN32~DN6000mm; Accuracy：≤1%; Velocity range：0~±10m/s, Bi-directional measurement; Interface：RS485, support MODBUS; Data storage：SD card regularly store the pre-set results(optional); Temperature：-30℃~160℃ (-85°F~320°F).
• ★MULTIPLE INSTALLATION METHODS - Installation methods: Wall mounting and Two ways of Din-rail mounting
• ★PACKAGE INCLUDING - 1 x TUF-2000B Host /1 x Steel Belt /1 x TM-1 Ultrasonic Transducer /2 x 5 meters Flow Signal Cable
• ★SERVICE GUARANTEE - Our products are sent from the US and can be delivered quickly. If you have any questions, please feel free to contact us. We will try our best to resolve your issue within 24 hours.
